FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
44
Drive No.
Drive Number Identified by the iBMC
3
3
⚫
4 x 3.5" drive pass-through configuration
Corresponds to 4 x 3.5" drive pass-through configuration 2 in 5.5.1 Drive
Configurations .
Figure 5-23 Slot Numbers
Table 5-11 Slot numbers
Drive No.
Drive Number Identified
by the iBMC
Drive Number Identified
by the RAID Controller
0
0
0
1
1
1
2
2
2
3
3
3
12
12
4
13
13
5
⚫
4 x 3.5" drive pass-through configuration
Corresponds to 4 x 3.5" drive pass-through configuration 3 in 5.5.1 Drive
Configurations .
Figure 5-24 Slot Numbers
Table 5-12 Slot numbers
Drive No.
Drive Number Identified
by the iBMC
Drive Number Identified
by the RAID Controller
