5 Hardware Description
2022-06-25
17
indicator
indicator
5
Power button/indicator
6
UID button/indicator
7
iBMC direct connect
management port indicator
-
-
⚫
8 x 2.5" drive configuration
Figure 5-5 Indicators and buttons on the front panel
1
Power button/indicator
2
UID button/indicator
3
iBMC direct connect
management port indicator
4
Fault diagnostic LED
5
Health status indicator
6
FlexIO card 1 presence
indicator
7
FlexIO card 2 presence
indicator
-
-
⚫
10 x 2.5" drive configuration
Figure 5-6 Indicators and buttons on the front panel
1
Fault diagnosis LED
2
Health status indicator
3
FlexIO card 1 presence
indicator
4
FlexIO card 2 presence
indicator
5
Power button/indicator
6
iBMC direct connect
management port indicator
7
UID button/indicator
-
-
