indicator for the management
network port
for the management network
port
3
Serial port indicators
NOTE
Reserved and unavailable
currently.
4
PSU indicators
5
UID indicator
-
-
Indicator Description
Table 5-3 Indicators on the rear panel
Silkscreen
Indicator
Description
-
Data transmission
status indicator for
the management
network port
⚫
Off: No data is being transmitted.
⚫
Blinking yellow: Data is being
transmitted.
-
Connection status
indicator for the
management
network port
⚫
Off: The network port is not connected.
⚫
Steady green: The network port is
connected properly.
-
PSU indicator
⚫
Off: No power is supplied.
⚫
Blinking green at 1 Hz:
− The input is normal, and the server is
standby.
− The input is overvoltage or
undervoltage.
− The PSU is in deep hibernation
mode.
⚫
Blinking green at 4 Hz: The firmware is
being upgraded online.
⚫
Steady green: The power input and
output are normal.
⚫
Steady orange: The input is normal but
there is no output.
NOTE
The possible causes of no power output are as
follows:
⚫
Power supply overtemperature protection
⚫
Power output overcurrent or short-circuit
⚫
Output overvoltage
⚫
Short-circuit protection
⚫
Device failure (excluding failure of all
devices)
