FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
60
7
2 x USB 3.0 ports (USB3.0
CONN/J88)
8
Rear VGA port (VGA
CONN/J60)
9
Serial port (COM/J6020)
10
BMC management network
port (BMC_GE /J6019)
11
BMC management board
12
OCP 3.0 network adapter 1
connector (OCP1
CONN/J108)
13
Rear 4-pin power connector 2
(REAR BP PWR2/J21)
14
NC-SI connector (NCSI
CONN/J114)
15
LP slimline 6 connector for
OCP 3.0 network adapter 1
(SLIMLINE6/J13)
16
PCIe riser 1 slot (PCIE
RISER1/J50)
17
TPM/TCM connector (J10)
18
Mini-SAS HD connector C
(MiniHD PORTC/J4)
19
Right mounting ear connector
(RCIA BOARD/J113)
20
Mini-SAS HD connector B
(MiniHD PORTB/J5)
21
Mini-SAS HD connector A
(MiniHD PORTA/J6)
22
SATA 9-pin connector 1
(SATA1/J1)
23
SATA 9-pin connector 2
(SATA2/J2)
24
Cell battery holder (U9)
25
VROC key connector (Soft
RAID KEY/J3)
a
26
LP slimline 1 connector
(SLIMLINE1/J11)
27
LP slimline 2 connector
(SLIMLINE2/J84)
28
Fan module 7 connector (1U
FAN7/J99)
29
Fan module 6 connector (1U
FAN6/J98)
30
Fan module 5 connector (1U
FAN5/J96)
31
Fan module 4 connector (1U
FAN4/J94)
32
Intrusion sensor connector
(INTRUDER CONN/S1)
33
Front low-speed signal
connector (FRONT HDD
BP/J75)
34
Fan module 3 connector (1U
FAN3/J92)
35
Fan module 2 connector (1U
FAN2/J101)
36
Fan module 1 connector (1U
FAN1/J67)
37
Left mounting ear connector
(LCIA BOARD/J106)
38
LP slimline 4 connector
(SLIMLINE4/J12)
39
LP slimline 3 connector
(SLIMLINE3/J85)
40
Front 14-pin power connector
1 (HDD BP PWR1/J26)
41
PSU 2 connector (PSU2/J56)
42
LP slimline 5 connector
(SLIMLINE5/J30)
43
Built-in low-speed signal
connector (INNER HDD
44
PSU 1 connector (PSU1/J28)
