FusionServer 1288H V6 Server
Technical White Paper
6 Product Specifications
2022-06-25
67
Component
Specifications
− Two USB 3.0 ports
− One DB15 VGA port
NOTE
The front panel of a server with 10 x 2.5" drives provides only one
USB Type-C iBMC direct connect management port and one USB 3.0
port.
⚫
Ports on the rear panel:
− Two USB 3.0 ports
− One DB15 VGA port
− One RJ45 serial port
− One RJ45 management network port
⚫
Built-in ports:
− Two SATA ports
NOTE
You are not advised to install the operating system on the USB storage
media.
Video card
An SM750 video chip with 32 MB display memory is
integrated on the mainboard. The maximum display resolution
is 1920 x 1200 at 60 Hz with 16 M colors.
NOTE
⚫
The integrated video card can provide the maximum display
resolution (1920 x 1200) only after the video card driver matching
the operating system version is installed. Otherwise, only the
default resolution supported by the operating system is provided.
⚫
If both the front and rear VGA ports are connected to monitors,
only the monitor connected to the front VGA port displays
information.
System management
⚫
UEFI
⚫
iBMC
⚫
NC-SI
⚫
Integration with third-party management systems
Security feature
⚫
Power-on password
⚫
Administrator password
⚫
TCM (only in China)/TPM
⚫
Secure boot
⚫
Front bezel (optional)
⚫
Chassis cover opening detection
