Xilinx KCU105 User Manual

KCU105 Board User Guide www.xilinx.com 71
UG917 (v1.4) September 25, 2015
Chapter 1: KCU105 Evaluation Board Features
C22 FMC_HPC_LA18 LVDS E22 D18 FMC_HPC_LA_13_N LVDS C9
C23 FMC_HPC_LA18 LVDS E23 D20 FMC_HPC_LA17_CC_P LVDS D24
C26 FMC_HPC_LA27 LVDS H21 D21 FMC_HPC_LA17_CC_N LVDS C24
C27 FMC_HPC_LA27 LVDS G21 D23 FMC_HPC_LA23_P LVDS G22
C30 FMC_HPC_IIC_SCL
(6)
U80.9 D24 FMC_HPC_LA23_N LVDS F22
C31 FMC_HPC_IIC_SDA
(6)
U80.8 D26 FMC_HPC_LA26_P LVDS G20
C34 GND D27 FMC_HPC_LA_26_N LVDS F20
C35 VCC12_SW D29 FMC_HPC_TCK_BUF
(3)
U19.17
C37 VCC12_SW D30 FPGA_TDO_FMC_TDI_BUF
(4)
U26.1
C39 UTIL_3V3_10A D31 FMC_HPC_TDO_LPC_TDI
(3)(4)
U19.21,
U26.2,
J2.D30
D32 UTIL_3V3_10A
D33 FMC_HPC_TMS_BUF
(3)
U19.20
D34 NC
D35 GND
D36 UTIL_3V3_10A
D38 UTIL_3V3_10A
D40 UTIL_3V3_10A
E/F Connections to FPGA U1
E2 FMC_HPC_HA01_CC_P LVDS E16 F1 FMC_HPC_PG_M2C
(7)
LVCMOS18 U44.18
E3 FMC_HPC_HA01_CC_N LVDS D16 F4 FMC_HPC_HA00_CC_P LVDS G17
E6 FMC_HPC_HA05_P LVDS J15 F5 FMC_HPC_HA00_CC_N LVDS G16
E7 FMC_HPC_HA05_N LVDS J14 F7 FMC_HPC_HA04_P LVDS G19
E9 FMC_HPC_HA09_P LVDS F18 F8 FMC_HPC_HA04_P LVDS F19
E10 FMC_HPC_HA09_N LVDS F17 F10 FMC_HPC_HA08_P LVDS K18
E12 FMC_HPC_HA13_P LVDS B14 F11 FMC_HPC_HA08_N LVDS K17
E13 FMC_HPC_HA13_N LVDS A14 F13 FMC_HPC_HA12_P LVDS K16
E15 FMC_HPC_HA16_P LVDS A19 F14 FMC_HPC_HA12_N LVDS J16
E16 FMC_HPC_HA16_N LVDS A18 F16 FMC_HPC_HA15_P LVDS D14
E18 FMC_HPC_HA20_P LVDS C19 F17 FMC_HPC_HA15_N LVDS C14
E19 FMC_HPC_HA20_N LVDS B19 F19 FMC_HPC_HA19_P LVDS D19
E21 NC F20 FMC_HPC_HA19_N LVDS D18
E22 NC F22 NC
E24 NC F23 NC
Table 1-23: FMC HPC J22 Connections to XCKU040 Device U1 (Cont’d)
J22
Pin
Schematic Net Name
I/O
Standard
XCKU040
(U1) Pin
J22 Pin Schematic Net Name I/O Standard
XCKU040
(U1) Pin
