Chapter 1: KCU105 Evaluation Board Features
E25 NC F25 NC
E27 NC F26 NC
E28 NC F28 NC
E30 NC F29 NC
E31 NC F31 NC
E33 NC F32 NC
E34 NC F34 NC
E36 NC F35 NC
E37 NC F37 NC
E39 VADJ_1V8 F38 NC
F40 VADJ_1V8
G/H Connections to FPGA U1
G2 FMC_HPC_CLK1_M2C_P LVDS E25 H1 NC
G3 FMC_HPC_CLK1_M2C_N LVDS D25 H2 FMC_HPC_PRSNT_M2C_B
(5)
LVCMOS18
U26.4,
U44.17
G6 FMC_HPC_LA00_CC_P LVDS H11 H4 FMC_HPC_CLK0_M2C_P LVDS H12
G7 FMC_HPC_LA00_CC_N LVDS G11 H5 FMC_HPC_CLK0_M2C_N LVDS G12
G9 FPC_HPC_LA03_P LVDS A13 H7 FMC_HPC_LA02_P LVDS K10
G10 FPC_HPC_LA03_N LVDS A12 H8 FMC_HPC_LA02_N LVDS J10
G12 FMC_HPC_LA08_P LVDS J8 H10 FMC_HPC_LA04_P LVDS L12
G13 FMC_HPC_LA08_N LVDS H8 H11 FMC_HPC_LA04_N LVDS K12
G15 FMC_HPC_LA12_P LVDS E10 H13 FMC_HPC_LA07_P LVDS F8
G16 FMC_HPC_LA12_N LVDS D10 H14 FMC_HPC_LA07_N LVDS E8
G18 FMC_HPC_LA16_P LVDS B9 H16 FMC_HPC_LA11_P LVDS K11
G19 FMC_HPC_LA16_N LVDS A9 H17 FMC_HPC_LA11_N LVDS J11
G21 FMC_HPC_LA20_P LVDS B24 H19 FMC_HPC_LA15_P LVDS D8
G22 FMC_HPC_LA20_N LVDS A24 H20 FMC_HPC_LA15_N LVDS C8
G24 FMC_HPC_LA22_P LVDS G24 H22 FMC_HPC_LA19_P LVDS C21
G25 FMC_HPC_LA22_N LVDS F25 H23 FMC_HPC_LA19_N LVDS C22
G27 FMC_HPC_LA25_P LVDS D20 H25 FMC_HPC_LA21_P LVDS F23
G28 FMC_HPC_LA25_N LVDS D21 H26 FMC_HPC_LA21_N LVDS F24
G30 FMC_HPC_LA29_P LVDS B20 H28 FMC_HPC_LA24_P LVDS E20
G31 FMC_HPC_LA29_N LVDS A20 H29 FMC_HPC_LA24_N LVDS E21
G33 FMC_HPC_LA31_P LVDS B25 H31 FMC_HPC_LA28_P LVDS B21
G34 FMC_HPC_LA31_N LVDS A25 H32 FMC_HPC_LA28_N LVDS B22
Table 1-23: FMC HPC J22 Connections to XCKU040 Device U1 (Cont’d)
J22
Pin
Schematic Net Name
I/O
Standard
XCKU040
(U1) Pin
J22 Pin Schematic Net Name I/O Standard
XCKU040
(U1) Pin
