Xilinx KCU105 User Manual

KCU105 Board User Guide www.xilinx.com 73
UG917 (v1.4) September 25, 2015
Chapter 1: KCU105 Evaluation Board Features
G36 FMC_HPC_LA33_P LVDS A27 H34 FMC_HPC_LA30_P LVDS C26
G37 FMC_HPC_LA33_N LVDS A28 H35 FMC_HPC_LA030_N LVDS B26
G39 VADJ_1V8 H37 FMC_HPC_LA32_P LVDS E26
H38 FMC_HPC_LA32_N LVDS D26
H40
VADJ_1V8
J/K Connections to FPGA U1
J2 NC K1 NC
J3 NC K4 NC
J6 FMC_HPC_HA03_P LVDS G15 K5 NC
J7 FMC_HPC_HA03_N LVDS G14 K7 FMC_HPC_HA02_P LVDS H19
J9 FMC_HPC_HA07_P LVDS L19 K8 FMC_HPC_HA02_N LVDS H18
J10 FMC_HPC_HA07_N LVDS L18 K10 FMC_HPC_HA06_P LVDS L15
J12 FMC_HPC_HA11_P LVDS J19 K11 FMC_HPC_HA06_N LVDS K15
J13 FMC_HPC_HA11_N LVDS J18 K13 FMC_HPC_HA10_P LVDS H17
J15 FMC_HPC_HA14_P LVDS F15 K14 FMC_HPC_HA10_N LVDS H16
J16 FMC_HPC_HA14_N LVDS F14 K16 FMC_HPC_HA17_CC_P LVDS E18
J18 FMC_HPC_HA18_P LVDS B17 K17 FMC_HPC_HA17_CC_N LVDS E17
J19 FMC_HPC_HA18_N LVDS B16 K19 FMC_HPC_HA21_P LVDS E15
J21 FMC_HPC_HA22_P LVDS C18 K20 FMC_HPC_HA21_N LVDS D15
J22 FMC_HPC_HA22_N LVDS C17 K22 FMC_HPC_HA23_P LVDS B15
J24 K23 FMC_HPC_HA23_N LVDS A15
J25 K25
J27 K26
J28 K28
J30 K29
J31 K31
J33 K32
J34 K34
J36 K35
J37 K37
J39 K38
Table 1-23: FMC HPC J22 Connections to XCKU040 Device U1 (Cont’d)
J22
Pin
Schematic Net Name
I/O
Standard
XCKU040
(U1) Pin
J22 Pin Schematic Net Name I/O Standard
XCKU040
(U1) Pin
