SP605 Hardware User Guide www.xilinx.com 15
UG526 (v1.9) February 14, 2019
Detailed Description
1. Spartan-6 XC6SLX45T-3FGG484 FPGA
A Xilinx Spartan-6 XC6SLX45T-3FGG484 FPGA is installed on the SP605 Evaluation Board.
See the Spartan-6 FPGA Data Sheet (DS162). [Ref 1]
Configuration
The SP605 supports configuration in the following modes:
• JTAG (using the included USB-A to Mini-B cable)
•JTAG (using System ACE CF and CompactFlash card)
•Master SPI x4
• Master SPI x4 with off-board device
• Linear BPI Flash
For details on configuring the FPGA, see Configuration Options.
Mode switch SW1 (see Table 1-32) is set to 10 = Slave SelectMAP to choose the System
ACE CF default configuration.
See the Spartan-6 FPGA Configuration User Guide (UG380) for more information. [Ref 2]
17
Switches
Power, Configuration,
Pushbutton Switches
14, 18, 20,
25
a. SP605 Power On-Off Slide
Switch
25
b. FPGA Mode DIP Switch 18
c. System ACE CF
Configuration DIP Switch
20
d. FPGA PROG, CPU Reset,
and System ACE CF Reset
Pushbutton Switches
14, 20
18 FMC LPC Connector Samtec ASP-134603-01 10
19
a. Power Management
Controller
2x TI UCD9240PFC 21, 26
b. Mini-Fit Type 6-Pin, ATX
Type 4-pin
12V input power connectors 25
Table 1-1: SP605 Features (Cont’d)
Number Feature Notes
Schematic
Page
