Xilinx SP605 User Manual

SP605 Hardware User Guide www.xilinx.com 55
UG526 (v1.9) February 14, 2019
Detailed Description
19. Power Management
AC Adapter and 12V Input Power Jack/Switch
The SP605 is powered from a 12V source that is connected through a 6-pin (2X3) right angle
Mini-Fit type connector J18. The AC-to-DC power supply included in the kit has a mating
6-pin plug.
When the SP605 is installed into a table top or tower PC's PCIe slot, the SP605 is typically
powered from the PC ATX power supply. One of the PC’s ATX hard disk type 4-pin power
connectors is plugged into SP605 connector J27. The SP605 can be powered with the AC
power adapter (plugged into J18) even when plugged into a PC PCIe motherboard slot;
G21 FMC_LA20_P R9 H20 FMC_LA15_N D19
G22 FMC_LA20_N R8 H22 FMC_LA19_P R11
G24 FMC_LA22_P V7 H23 FMC_LA19_N T11
G25 FMC_LA22_N W8 H25 FMC_LA21_P V11
G27 FMC_LA25_P W14 H26 FMC_LA21_N W11
G28 FMC_LA25_N Y14 H28 FMC_LA24_P AA14
G30 FMC_LA29_P T15 H29 FMC_LA24_N AB14
G31 FMC_LA29_N U15 H31 FMC_LA28_P AA16
G33 FMC_LA31_P U16 H32 FMC_LA28_N AB16
G34 FMC_LA31_N V15 H34 FMC_LA30_P Y15
G36 FMC_LA33_P Y17 H35 FMC_LA30_N AB15
G37 FMC_LA33_N AB17 H37 FMC_LA32_P W17
H38 FMC_LA32_N Y18
Table 1-28: VITA 57.1 FMC LPC Connections (Cont’d)
J63 FMC
LPC Pin
Schematic Net Name
U1 FPGA
Pin
J63 FMC
LPC Pin
Schematic Net Name
U1 FPGA
Pin
Table 1-29: Power Supply Voltages for LPC Connector
Voltage Supply Voltage
Number
of Pins
Maximum
Current
Tolerance
VADJ Fixed 2.5V 2 2A ±5%
VIO_B_M2C NC 0 0A N/A
VREF_A_M2C 0-VADJ 1 0.001A ±2%
VREF_B_M2C NC 0 0A N/A
3P3VAUX 3.3V 1 0.020A ± 5%
3P3V 3.3V 4 3A ±5%
12P0V 12V 2 1A ±5%
