Chapter 1: SP605 Evaluation Board
SP605 board. The 6-pin Mini-Fit type connector is marked with a no PCIe power label to warn
users of the potential hazard.
See the Spartan-6 FPGA GTP Transceivers User Guide (UG386) for more information. [Ref 6]
Also, see the following websites for more information about the Spartan-6 FPGA Integrated
Endpoint Block for PCI Express:
Product information, www.xilinx.com/products/intellectual-
property/s6_pci_express_block.html
In addition, see the PCI Express specifications for more information. [Ref 19]
