Xilinx SP605 User Manual

40 www.xilinx.com SP605 Hardware User Guide
UG526 (v1.9) February 14, 2019
Chapter 1: SP605 Evaluation Board
See the ST Micro M24C08 Data Sheet for more information. [Ref 21]
In addition, see the Xilinx XPS IIC Bus Interface Data Sheet (DS606). [Ref 8]
Table 1-20: IIC Memory Connections
U1 FPGA Pin Schematic Netname
IIC Memory U4
Pin Number Pin Name
Not Applicable Tied to GND 1 A0
Not Applicable Tied to GND 2 A1
Not Applicable Pulled up (0Ω) to VCC3V3 3 A2
R22 IIC_SDA_MAIN 5 SDA
T21 IIC_SCL_MAIN 6 SCL
Not Applicable Tied to GND 7 WP
