VCU118 System Controller
˃ Two versions of the VCU118 firmware.
Original firmware (v1.1) will not correctly set VADJ if the FMC card EEPROM is unprogrammed.
New firmware (v2.30) fixes this problem and runs faster with the SCUI.
BIT works with either version of Firmware
˃ Version 1.1 SCUI:
Firmware: v1.00
The ES1 VCU118 ships with v1.00 firmware. Some Rev 2.0 boards shipped with this.
You must use SCUI v1.1 with this firmware.
˃ Version 2.30 SCUI:
Firmware: v1.60
Current Rev 2.0 VCU118 shipping with this firmware.
You must use SCUI v2.30 with this firmware.
Note: Presentation applies to the VCU118
