Installation and Licensing of ISE Design Suite
10. The ISE software license has been successfully installed. Click OK on the Success
Dialog (Figure 35) and close the Xilinx License Configuration Manager.
Congratulations! The ISE Design Suite tools are now installed and the licenses are set up
for the Embedded Edition of the tools.
For detailed information on licensing and installation, refer to UG631, ISE Design Suite:
Installation, Licensing, and Release Notes, located on the Xilinx documentation site at
http://www.xilinx.com/support/documentation
.
Now that the FPGA-based connectivity demonstration has been set up and evaluated and
the ISE Design Suite Logic plus Embedded Edition is completely installed, the connectivity
design for the Virtex-6 LX240T FPGA can be modified. This step enables the designer to
understand the simplified flow of the Xilinx tools and design methodologies as they apply
to the Virtex-6 FPGA Connectivity Kit and the Virtex-6 FPGA Connectivity Targeted
Reference Design.
X-Ref Target - Figure 35
Figure 35: License Installation Successful
UG664_36_011710
