32 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
AF30 FMC1_HA10_P K13
AG31 FMC1_HA10_N K14
AH28 FMC1_HA11_P J12
AJ28 FMC1_HA11_N J13
AC31 FMC1_HA12_P F13
AD31 FMC1_HA12_N F14
AA31 FMC1_HA13_P E12
AA32 FMC1_HA13_N E13
AC30 FMC1_HA14_P J15
AD30 FMC1_HA14_N J16
AA29 FMC1_HA15_P F16
AA30 FMC1_HA15_N F17
AB29 FMC1_HA16_P E15
AC29 FMC1_HA16_N E16
AB33 FMC1_HB00_CC_P K25
AC33 FMC1_HB00_CC_N K26
AF35 FMC1_HB01_P J24
AF36 FMC1_HB01_N J25
AE37 FMC1_HB02_P F22
AF37 FMC1_HB02_N F23
AF34 FMC1_HB03_P E21
AG34 FMC1_HB03_N E22
AD36 FMC1_HB04_P F25
AD37 FMC1_HB04_N F26
AC35 FMC1_HB05_P E24
AC36 FMC1_HB05_N E25
AB31 FMC1_HB06_CC_P K28
AB32 FMC1_HB06_CC_N K29
AG36 FMC1_HB07_P J27
AH36 FMC1_HB07_N J28
Y37 FMC1_HB08_P F28
AA37 FMC1_HB08_N F29
Y35 FMC1_HB09_P E27
Table 1-18: VITA 57.1 FMC1 HPC Connections at JA2 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
