Detailed Description
AA36 FMC1_HB09_N E28
AB36 FMC1_HB10_P K31
AB37 FMC1_HB10_N K32
AA34 FMC1_HB11_P J30
AA35 FMC1_HB11_N J31
AE32 FMC1_HB12_P F31
AE33 FMC1_HB12_N F32
AF31 FMC1_HB13_P E30
AF32 FMC1_HB13_N E31
AE34 FMC1_HB14_P K34
AE35 FMC1_HB14_N K35
AE29 FMC1_HB15_P J33
AE30 FMC1_HB15_N J34
Y32 FMC1_HB16_P F34
Y33 FMC1_HB16_N F35
AU38 FMC1_LA00_CC_P G6
AV38 FMC1_LA00_CC_N G7
AU39 FMC1_LA01_CC_P D8
AV39 FMC1_LA01_CC_N D9
AN38 FMC1_LA02_P H7
AP38 FMC1_LA02_N H8
AM41 FMC1_LA03_P G9
AM42 FMC1_LA03_N G10
AR38 FMC1_LA04_P H10
AR39 FMC1_LA04_N H11
AN40 FMC1_LA05_P D11
AN41 FMC1_LA05_N D12
AR37 FMC1_LA06_P C10
AT37 FMC1_LA06_N C11
AM39 FMC1_LA07_P H13
AN39 FMC1_LA07_N H14
AP40 FMC1_LA08_P G12
AR40 FMC1_LA08_N G13
Table 1-18: VITA 57.1 FMC1 HPC Connections at JA2 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
