34 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
AP41 FMC1_LA09_P D14
AP42 FMC1_LA09_N D15
AT39 FMC1_LA10_P C14
AT40 FMC1_LA10_N C15
AR42 FMC1_LA11_P H16
AT42 FMC1_LA11_N H17
AW37 FMC1_LA12_P G15
AY37 FMC1_LA12_N G16
BA37 FMC1_LA13_P D17
BB37 FMC1_LA13_N D18
AW38 FMC1_LA14_P C18
AY38 FMC1_LA14_N C19
BB38 FMC1_LA15_P H19
BB39 FMC1_LA15_N H20
BA39 FMC1_LA16_P G18
BA40 FMC1_LA16_N G19
AK34 FMC1_LA17_CC_P D20
AL34 FMC1_LA17_CC_N D21
AJ33 FMC1_LA18_CC_P C22
AK33 FMC1_LA18_CC_N C23
AM36 FMC1_LA19_P H22
AN36 FMC1_LA19_N H23
AJ36 FMC1_LA20_P G21
AJ37 FMC1_LA20_N G22
AP36 FMC1_LA21_P H25
AP37 FMC1_LA21_N H26
AK37 FMC1_LA22_P G24
AL37 FMC1_LA22_N G25
AN35 FMC1_LA23_P D23
AP35 FMC1_LA23_N D24
AL36 FMC1_LA24_P H28
AM37 FMC1_LA24_N H29
AG33 FMC1_LA25_P G27
Table 1-18: VITA 57.1 FMC1 HPC Connections at JA2 (Cont’d)
