ZCU104 Board User Guide 69
UG1267 (v1.1) October 9, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Figure 3-25 shows the power and status LEDs area of the board.
DS54 PS_DDR4_VTERM_0V60_PGOOD Green PS_DDR4_VTERM 0.6 VDC power on
Notes:
1. See the Zynq UltraScale+ MPSoC Technical Reference Manual (UG1085) [Ref 2] for more information about Zynq UltraScale+
MPSoC configuration pins.
Table 3-25: Power and Status LEDs (Cont’d)
Ref. Des. Net Name LED Color Description
X-Ref Target - Figure 3-25
Figure 3-25: Power and Status LEDs
X20118-012618
Send Feedback
