Xilinx ZCU111 User Manual

ZCU111 Board User Guide 104
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Appendix D: HW-FMC-XM500
87
IO_L12N_AD8N_87_A9 A9 DACIO_00
J94
A37
J888
1
J9 2x10
Male-Pin
Header
IO_L12P_AD8P_87_A10 A10 DACIO_01 A39 3
IO_L11N_AD9N_87_A6 A6 DACIO_02 B36 5
IO_L11P_AD9P_87_A7 A7 DACIO_03 B38 7
IO_L10N_AD10N_87_A5 A5 DACIO_04 B40 9
IO_L10P_AD10P_87_B5 B5 DACIO_05 C37 11
IO_L9N_AD11N_87_C5 C5 DACIO_06 C39 13
IO_L9P_AD11P_87_C6 C6 DACIO_07 D36 15
IO_L8N_HDGC_87_B9 B9 DACIO_08 D28 17
IO_L8P_HDGC_87_B10 B10 DACIO_09 D40 19
IO_L7N_HDGC_87_B7 B7 DACIO_10 E37 20
IO_L7P_HDGC_87_B8 B8 DACIO_11 E39 18
IO_L6N_HDGC_87_D8 D8 DACIO_12 F36 16
IO_L6P_HDGC_87_D9 D9 DACIO_13 F38 14
IO_L5N_HDGC_87_C7 C7 DACIO_14 F40 12
IO_L5P_HDGC_87_C8 C8 DACIO_15 G37 10
IO_L4N_AD12N_87_C10 C10 DACIO_16 G39 8
IO_L4P_AD12P_87_D10 D10 DACIO_17 H36 6
IO_L3N_AD13N_87_D6 D6 DACIO_18 H38 4
IO_L3P_AD13P_87_E7 E7 DACIO_19 H40 2
Table D-4: ZCU111 U1 RFSoC Bank 84 ADCIO and Bank 87 DACIO Connections to XM500 (Cont’d)
ZCU111 Board (with LPAF)
Mated
Conns
XM500 RFMC Card (with LPAM)
ZU28DR
U1 Bank
ZU28DR U1 Pin Name
ZU28DR
U1 Pin
ZCU111 Net
Name
ZCU111
LPAF
LPAF/M
Pin
XM500
LPAM
2x10
Header Pin
XM500
Header
Send Feedback
