Xilinx ZCU111 User Manual

ZCU111 Board User Guide 93
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Appendix D
HW-FMC-XM500
Overview
The ZU28DRF-FFVG1517 contains eight multi-gigasample (4 GSPS), 12-bit RF
analog-to-digital converter (RF-ADC) channels across four banks and eight
multi-gigasample (6.544 GSPS), 14-bit RF digital-to-analog (RF-DAC) converter channels
across two banks. The ZCU111 board provides a pair of Samtec LPAF connectors for the
RF-ADC/RF-DAC clock and RF signals. The FMC-XM500 is an out-of-the-box AMS RFMC
plug-in card that mates with the ZCU111 board via two Samtec LPAM (8x40) connectors on
the bottom of the XM500 card with connectivity featuring:
• Two DACs and two ADCs routed to HF baluns with –1dB Pi pad attenuators and then to
SMAs
• Two DACs and two ADCs routed to LF baluns with –3dB Pi pad attenuators and then to
SMAs
• Four DACs and four ADCs routed to SMAs for use with external custom baluns and
filters
• Four pairs external input clocks for ADCs
• Four pairs external input clocks for DACs
