Chapter 3: Board Component Descriptions
AF17 GPIO_DIP_SW1 LVCMOS18 SW14.7
AH15 GPIO_DIP_SW2 LVCMOS18 SW14.6
AH16 GPIO_DIP_SW3 LVCMOS18 SW14.5
AH17 GPIO_DIP_SW4 LVCMOS18 SW14.4
AG17 GPIO_DIP_SW5 LVCMOS18 SW14.3
AJ15 GPIO_DIP_SW6 LVCMOS18 SW14.2
AJ16 GPIO_DIP_SW7 LVCMOS18 SW14.1
Directional Pushbuttons (Active High)
AW3 GPIO_SW_N LVCMOS18 SW9.3
AW6 GPIO_SW_W LVCMOS18 SW10.3
AW5 GPIO_SW_C LVCMOS18 SW11.3
AW4 GPIO_SW_E LVCMOS18 SW12.3
E8 GPIO_SW_S LVCMOS18 SW13.3
CPU Reset Pushbutton (Active High)
AF15 CPU_RESET LVCMOS18 SW15.3
Notes:
1. Level-shifted net names at ZU28DR U1 have _LS appended.
Table 3-24: GPIO Connections to XCZU28DR (Cont’d)
XCZU28DR (U1) Pin Net Name I/O Standard Device
