Xilinx ZCU111 User Manual

ZCU111 Board User Guide 70
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
DS24 DAC_AVCC_PG Green ADC_AVCC 0.925V power on
DS25 VADJ_FMC_PG Green VADJ_FMC 1.8VDC (Nom.) power on
DS26 MGT1V2_PG Green MGT1V2 1.2VDC power on
DS43 MGTAVCC_PG Green MGTAVCC 0.9VDC power on
DS28 MGT1V8_PG Green MGT1V8 1.8VDC power on
DS29 MGTRAVCC_PG Green MGTRAVCC 0.85VDC power on
DS30 VCCINT_RF_PG Green VCCINT_RF 0.85VDC power on
DS31 ADC_AVCC_PG Green ADC_AVCC 0.925VDC power on
DS32 UTIL_3V5_PG Green UTIL_3V5 3.5VDC power on
DS33 ADC_AVCCAUX_PG Green ADC_AVCCAUX 1.8VDC power on
DS34 MUXOUT_RF1 Green LMX2594 U102 lock detect
DS35 MUXOUT_RF2 Green LMX2594 U103 lock detect
DS36 UTIL_1V13_PG Green UTIL_1V13 1.13VDC power on
DS37 UTIL_2V5_PG Green UTIL_2V5 2.5VDC power on
DS38 UTIL_3V3_PG Green UTIL_3V3 3.3VDC power on
DS39 UTIL_5V0_PG Green UTIL_5V0 5VDC power on
DS40 PS_DDR4_VTERM_0V60_PGOOD Green PS_DDR4_VTERM 0.6VDC power on
DS41 PL_DDR4_VTERM_0V60_PGOOD Green PL_DDR4_VTERM 0.6VDC power on
DS42 DAC_AVCCAUX_ON Green DAC_AVCCAUX 1.8VDC power on
DS44 MUXOUT_RF3 Green LMX2594 U104 lock detect
DS45 STATUS_4208 Green LMK04208 status
DS49 DAC_AVTT_PG Green DAC_AVTT 2.5VDC power on
DS8 RF_CLK_VCC3V3_PG Green RF_CLK_VCC3V3 3.3VDC power on
DS50 MIO23_LED Green RFSoC U1 bank 500 GPIO LED
Table 3-25: Power and Status LEDs (Cont’d)
Ref. Des. Schematic Net Name LED Color Description
Send Feedback
