Xilinx ZCU111 User Manual

ZCU111 Board User Guide 96
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Appendix D: HW-FMC-XM500
Table D-1: XM500 Card Components Locations
Callout
No.
Ref Des. Feature Notes
Schematic
0381858
Page
1 J333
ADC connector,
low profile array (LPAM) terminal
Samtec
LPAM-40-010-S-08-2-K-TR
3
2 J888
DAC connector,
low profile array (LPAM) terminal
Samtec
LPAM-40-010-S-08-2-K-TR
4
3 MH15,16,17
Mounting holes for the jackscrew of
LPAF connector mounting system
Jackscrew attached with
ZCU111 board
2
4 U8, U9, J3, J4
Two channels ADC Low frequency
baluns with -3dB attenuators to SMAs
Mini-Circuits TCM2-33WX+ 2
5 U6, U7, J1, J2
Two channels ADC High frequency
baluns with -1dB attenuators to SMAs
Anaren BD1631J50100AHF 2
6 U1, U3, J7, J8
Two channels DAC High frequency
baluns with -1dB attenuators to SMAs
Anaren BD1631J50100AHF 2
7 U4, U5, J5, J6
Two channels DAC Low frequency
baluns with -3dB attenuators to SMAs
Mini-Circuits TCM2-33WX+ 2
8 J32-J37, J39, J40 Four channels ADCs to SMAs
Molex Screw-on SMA:
0732513481
3
9
J30, J31, J891-J894,
J889, J890
Four pairs external input clock SMAs
for ADC
Molex Screw-on SMA:
0732513481
3
10 J28, J29, J895-J900
Four pairs external input clock SMAs
for DAC
Molex Screw-on SMA:
0732513481
4
11 J20-J27 Four channels DACs to SMAs
Molex Screw-on SMA:
0732513481
4
12 J10 20 ADC I/Os to 2x10 header 2.54mm 2x10 header 3
13 J9 20 DAC I/Os to 2x10 header 2.54mm 2x10 header 4
14 MH11-MH14 Mounting holes for standoff
#4-40 0.625" alum standoffs
(5/8" or 15.9mm)
2
Send Feedback
