Xinje DS3E Series User Manual

P1-18
mode
22
Speed command filter
0: first order low-pass filter
1: smoothing filter
-
0
0
√
3, 4, 7
5-4-9
23
Speed command filter time
0.1ms
0
0~65535
√
3, 4, 7
5-4-9
24
Position command filter
0: first order low-pass filter
1: smoothing filter
-
0
0~1
√
6, 10
5-3-4
25
Position command filter time
0.1ms
0
0~65535
√
6, 10
5-3-4
P2: parameters (reserved)
P3: speed control
P3-
XX
Name
Unit
Default
value
Range
Effecti
ve
Suitable
mode
Chapter
00
V-REF function distribution
0: V-REF is speed command
input
1: V-REF is external speed
limit input, actual speed limit
depend on external analog
speed limit
2: speed feedforward
—
0
0~2
○
1, 2, 4, 6
5-4-2/
5-7-5
01
Rated speed corresponding
to analog voltage
0.01V
1000
150~3
000
○
1, 2, 4, 6
5-4-2
02
Analog voltage speed filter
0.01ms
0
0~100
00
√
1, 2, 4, 6
5-4-2
03
Speed command input dead
area voltage
0.01v
0
0~100
√
1, 2, 4, 6
5-4-2
05
Preset speed 1
rpm
0
-9999~
+9999
√
3
5-5-2
06
Preset speed 2
rpm
0
-9999~
+9999
√
3
5-5-2
07
Preset speed 3
rpm
0
-9999~
+9999
√
3
5-5-2
09
Acceleration time
ms
0
0~
65535
○
3, 4
5-4-8
10
Deceleration time
ms
0
0~
65535
○
3, 4
5-4-8
11
Reserved
12
Zero speed clamp mode
0: ZCLAMP input signal is
ON, forced speed command
is 0. When the speed below
P3-13, switch to position
mode and the servo locked in
this position
1: ZCLAMP input signal is
ON, forced set speed
command to 0
2: ZCLAMP input signal is
ON, speed below P3-13
switch to position mode and
the servo locked in this
position
—
0
0~2
○
3, 4, 7
5-4-5
13
Zero speed clamp speed
rpm
10
0~
10000
○
3, 4
5-4-5
