Xinje XC Series User Manual

2 The Specifications and Parameters of CPU
Timer
points
640 points
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
T600~T639：1ms precise time
Spec.
100ms timer: set time 0.1~3276.7sec.
10ms timer: set time 0.01~327.67sec.
1ms timer: set time 0.001~32.767sec.
Counter (C)
points
640
points
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
C630~C639：AB phase high speed counter
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
Data Register (D)
9024
words
D0~D3999
【D4000~D4999】
※
5
For Special Use
※
6
D8000~D9023
Flash ROM Register (FD)
8192
words
FD0~FD7167
For Special Use
※
6
FD8000~FD9023
Expand the internal
registers (ED)
※
7
36864
words
ED0~ED36863
High Speed Dispose
Ability
High speed counter, pulse output, external interruption
Password Protection
6 bits ASCII
Self-diagnose Function
Power on self-check、monitor the timer、grammar check
Items
Specifications
Program Executing Form
Loop scan form
Program Form
Instruction, Ladder
Dispose Speed
0.5 us
Power Off Retentive
Use Flash ROM and Li battery
User's program space
※
1
160KB
I/O points
Total I/O
24
32
60
XCM Series
