Xinje XC Series User Manual

2 The Specifications and Parameters of CPU
※
2
Input
14
X0~X015
18
X0~X021
36
X0~X43
Output
10
Y0~Y011
14
Y0~Y015
20
Y0~Y27
Internal Coils (X)
※
3
X0~X1037 (Total 544)
Internal Coils (Y)
※
4
Y0~Y1037 (Total 544)
Internal Coils (M)
8768 points
M0~M2999
【M3000~M7999】
※
5
For Special Use
※
6
M8000~M8767
Flow (S)
1024 points
S0~S511
【S512~S1023】
Timer
points
640 points
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
T600~T639：1ms precise time
Spec.
100ms timer: set time 0.1~3276.7sec.
10ms timer: set time 0.01~327.67sec.
1ms timer: set time 0.001~32.767sec.
Counter (C)
points
640 points
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
C630~C639：AB phase high speed counter
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
Data Register (D)
5024 words
D0~D2999
【D4000~D4999】
※
5
For Special Use
※
6
D8000~D9023
FlashROM register (FD)
1996 words
FD0~FD1535
For Special Use
※
6
FD8000~FD8349
For Special Use
※
6
FD8890~FD8999
Expand the internal
registers (ED)
※
7
36864 words
ED0~ED36863
High Speed Dispose
Ability
High speed counter, pulse output, external interruption
Password Protection
6 bits ASCII
Self-diagnose Function
Power on self-check、monitor the timer、grammar check
