OVEN DESCRIPTION
This manual covers the following XLT Oven & Hood models:
Food product is placed on the stainless steel wire conveyor belt on one side of the oven.
The conveyor then transports the food through the bake chamber at a user-controlled speed. This
provides repeatable and uniform food cooking. The conveyors can be easily configured to move
either left-to-right or right-to-left with a simple programming change. A large center sandwich
door allows the introduction or removal of food items for cooking at shorter times. Precise tem-
peratures are user adjustable and maintained by a digital control.
An easily removable front panel allows the full cleaning of the oven interior. All exposed
oven surfaces both exterior and interior are stainless steel. The conveyor is a one piece design and
is removed from the side which has the control box. No tools are required for disassembly and
cleaning of the conveyor or oven interior. The oven itself is mounted on lockable swivel casters
for easy moving and maintenance.
Accessories such as extended conveyor shelves, base shelves, extended fronts, fire suppres-
sion components, and perforated crumb trays are available from XLT. In addition, moving equip-
ment such as carts and lifting jacks are available to help install and move ovens. Please contact
XLT Ovens or your Authorized Distributor for more information.
OVEN DESCRIPTION
The first 2 digits of the model number after the dash represent the conveyor width and the
last two digits indicate the bake chamber length. The five x’s after those numbers represents the
oven and hood configuration number. The HP after the five x’s represents the faster baking high
performance ovens. The 3270 & 3870 models have two burners, one on each side, & have two
control boxes. All other models have only a single burner with a single control box that can be
supplied on either end. The ovens may be used in a single, double, or triple oven stack configura-
tion. All ovens are gas-fired & are available in Natural gas or Liquid Petroleum gas models
(Electric ovens are also available). All models can be configured for a split belt conveyor.
X3F3-1832-xxxxx X3F3-1832-xxxxx-HP H3E-1832-xxxxx
X3F3-2440-xxxxx X3F3-2440-xxxxx-HP H3E-2440-xxxxx
X3F3-3240-xxxxx X3F3-3240-xxxxx-HP H3E-3240-xxxxx
X3F3-3255-xxxxx X3F3-3255-xxxxx-HP H3E-3255-xxxxx
X3F3-3270-xxxxx X3F3-3270-xxxxx-HP H3E-3270-xxxxx
X3F3-3855-xxxxx X3F3-3855-xxxxx-HP H3E-3855-xxxxx
X3F3-3870-xxxxx X3F3-3870-xxxxx-HP H3E-3870-xxxxx
