Type 4 - Vehicle Wiring Reference Chart
Function Wire Color Pin Polarity Location
Color Pins
Mazda CX-9 2011-2014
12V Red 6 (+) Ignition switch. White 6
Ignition Blue 2 (+) Ignition switch. White 6
Accessory Black/Red 4 (+) Ignition switch. White 6
Accessory 2 Black/White 5 (+) Ignition switch. White 6
Starter Black/Blue 1 (+) Ignition switch. White 6
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low Blue 14 Data OBDII. Black 16
RX Blue/Orange 1 Data Immobilizer Module around ignition switch. White 4
TX Blue/Yellow 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Brown or Brown/White 14 (-) Headlight switch. White 17
Door Lock (WO/ Alarm) Violet/White 26 MUX
BCM in drivers kick. White 30
Door Lock (W/ Alarm) Lt. Green 12 MUX BCM in drivers kick. White 30
Brake Green/Yellow N/A (+) Driver kick panel. N/A N/A
Trunk Input Lt. Green/Red 10 (-) BCM in drivers kick. White 24
Trunk Release White/Green and White/Black 2 and 4 Short
Power lifgate switch, use relay to short
White/Green and White Black together.
White 12
Mazda CX-9 (Smart Key) 2011-2014
12V Red 6 (+) Ignition switch. White 6
Ignition Blue 2 (+) Ignition switch. White 6
Accessory Black/Red 4 (+) Ignition switch. White 6
Accessory 2 Black/White 5 (+) Ignition switch. White 6
Starter Black/Blue 1 (+) Ignition switch. White 6
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low Blue 14 Data OBDII. Black 16
RX Blue/Orange 1 Data Immobilizer Module around ignition switch. White 4
TX Blue/Yellow 2 Data
Immobilizer Module around ignition switch. White 4
Parking Light Brown or Brown/White 14 (-) Headlight switch. White 17
Door Lock (WO/ Alarm) Violet/White 26 MUX BCM in drivers kick. White 30
Door Lock (W/ Alarm) Lt. Green 12 MUX
BCM in drivers kick. White 30
Brake Green/Yellow N/A (+) Driver kick panel. N/A N/A
Trunk Input Lt. Green/Red 10 (-)
BCM in drivers kick. White 24
Trunk Release White/Green and White/Black 2 and 4 Short
Power lifgate switch, use relay to short
White/Green and White Black together.
White 12
