Xpresskit DBALL2 User Manual

Rev.: 20170926
Platform: DBALL2
Firmware: MA2
© 2017 Directed. All rights reserved.
Page 8
Type 2 - Vehicle Wiring Reference Chart
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins
Mazda CX-9 2007-2010 (Smart Key)
12V Red 6 (+) Ignition switch. White 6
Ignition Blue 2 (+) Ignition switch. White 6
Accessory Black/Red 4 (+) Ignition switch. White 6
Starter Black/Blue 1 (+) Ignition switch. White 6
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low Blue 14 Data OBDII. Black 16
RX Blue/Orange 1 Data Immobilizer Module around ignition switch. White 4
TX Blue/Yellow 2 Data
Immobilizer Module around ignition switch. White 4
Parking Light Brown or Brown/White 14 (-) Headlight switch. White 17
Trunk Release White/Green & White/Black 1 & 3 Short
Power liftgate switch, use relay to short White/Green and
White/Black together.
White 6
Door Lock (WO/Alarm) Volet/White 26 MUX BCM above Drivers kick. White 30
Door Lock (W/Alarm) Lt. Green 12 MUX BCM above Drivers kick. White 30
Mazda MazdaSpeed3 2006-2009
12V Red 4 (+)
Ignition switch. White 6
Ignition Green/Yellow 1 (+) Ignition switch. White 6
Accessory Pink/Yellow 6 (+) Ignition switch. White 6
Starter Gray/Black 5 (+) Ignition switch. White 6
HS CAN High Gray/Violet 6 Data OBDII. Black 16
HS CAN Low Blue/White 14 Data OBDII. Black 16
RX White/Green 1 Data Immobilizer Module around ignition switch. White 4
TX Gray/Orange 2 Data
Immobilizer Module around ignition switch. White 4
Parking Light Black/White 1 (-) Headlight switch. White 12
Door Lock (WO/Alarm) Green/Red to Black/Blue N/A MUX Drivers kick panel. White N/A
Door Lock (W/Alarm) Black/Blue N/A MUX Drivers kick panel. White N/A
Mazda MazdaSpeed6 2006-2008
12V Black/Yellow 6 (+) Ignition switch. White 6
Ignition Blue 2 (+) Ignition switch. White 6
Accessory Black/Red 4 (+) Ignition switch. White 6
Starter Black/Blue 1 (+) Ignition switch. White 6
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low Blue 14 Data OBDII. Black 16
RX Orange/Blue or Gray 1 Data Immobilizer Module around ignition switch. White 4
TX Green or Yellow/Green 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Red/White 14 (-) Headlight switch. White 17
Trunk Release Yellow 1 (-) Trunk release switch. White 2
Door Lock (WO/Alarm) Lt. Green 7 MUX BCM drivers kick. White 24
Door Lock (W/Alarm) Blue or Blue/White 17 MUX BCM drivers kick. White 24
Mazda MX-5 Miata 2006-2015
12V White/Green 3 (+) Ignition switch. White 6
Ignition Green/White 2 (+) Ignition switch. White 6
Accessory Pink/Black 4 (+) Ignition switch. White 6
Starter White/Blue 1 (+) Ignition switch. White 6
HS CAN High Blue/White 6 Data OBDII. Black 16
HS CAN Low Green/Black 14 Data OBDII. Black 16
RX Blue/Orange or Violet 1 Data Immobilizer Module around ignition switch. White 4
TX Yellow/Black or Gray/Blue 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Brown/Black 14 (-) Headlight switch. White 17
Door Lock (WO/Alarm) Brown/White 10 MUX Keyless Control Module above drivers kick. White 27
Door Lock (W/Alarm) Gray/Red 3 MUX Keyless Control Module above drivers kick. White 27
