Xpresskit DBALL2 User Manual

Rev.: 20170926
Platform: DBALL2
Firmware: MA2
© 2017 Directed. All rights reserved.
Page 15
Type 5 - Vehicle Wiring Reference Chart
Function Wire Color Pin Polarity Location
Color Pins
Mazda 3 2004-2009
12V Red 4 (+) Ignition switch. White 8
Ignition Green/Yellow 1 (+) Ignition switch. White 8
Accessory Pink/Yellow 6 (+) Ignition switch. White 8
Starter Gray/Black 5 (+) Ignition switch. White 8
HS CAN High Gray/Violet 6 Data OBDII. Black 16
HS CAN Low Blue/White 14 Data OBDII. Black 16
MS CAN High Gray/Violet 3 Data OBDII. Black 16
MS CAN Low Blue/White 11 Data OBDII. Black 16
RX White/Green 1 Data Immobilizer Module around ignition switch. White 4
TX Gray/Orange 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Black/White 1 (-) Headlight switch. White 12
Door Lock (WO/Alarm) Green/Red to Black/Blue N/A MUX Drivers kick panel. N/A N/A
Door Lock (W/Alarm) Black/Blue N/A MUX Drivers Kick panel. N/A N/A
Mazda 5 2006-2007
12V Black/Yellow 8 (+) Ignition switch. White 8
Ignition Blue 1 (+) Ignition switch. White 8
Accessory Black/Red 6 (+) Ignition switch. White 8
Starter Black/Blue 5 (+) Ignition switch. White 8
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low Blue 14 Data OBDII. Black 16
MS CAN High Blue/Whie 3 Data OBDII. Black 16
MS CAN Low Gray 11 Data OBDII. Black 16
RX Pink/Black 1 Data Immobilizer Module around ignition switch. White 4
TX Green 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Brown/Red 1 (-) Headlight switch. White 12
Door Lock Blue N/A MUX Drivers kick panel. N/A N/A
Mazda 5 2008-2010
12V Black/Yellow 8 (+) Ignition switch. White 8
Ignition Blue 1 (+) Ignition switch. White 8
Accessory Black/Red 6 (+) Ignition switch. White 8
Starter Black/Blue 5 (+) Ignition switch. White 8
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low White 14 Data OBDII. Black 16
MS CAN High Violet 3 Data OBDII. Black 16
MS CAN Low Gray 11 Data OBDII. Black 16
RX Pink/Black 1 Data Immobilizer Module around ignition switch. White 4
TX Green 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Brown/Red 1 (-) Headlight switch. White 12
Door Lock Blue N/A MUX Drivers kick panel. N/A N/A
