Xpresskit DBALL2 User Manual

Rev.: 20170926
Platform: DBALL2
Firmware: MA2
© 2017 Directed. All rights reserved.
Page 4
Type 1 - Vehicle Wiring Reference Chart
Function Wire Color Pin Polarity Location
Color Pins
Mazda 2 2011-2014
12V Red 3 (+) Ignition switch. White 6
Ignition Black/Yellow 5 (+) Ignition switch. White 6
Accessory Black/Red 1 (+) Ignition switch. White 6
Starter Black/Blue 2 (+) Ignition switch. White 6
HS CAN High Red 6 Data OBDII. Black 16
HS CAN Low Blue 14 Data OBDII. Black 16
RX Gray 4 Data
Immobilizer Module around ignition switch.
(PATS connector A).
White 6
TX Green 3 Data
Immobilizer Module around ignition switch.
(PATS connector A).
White 6
Parking Light Brown/White 8 (-) Headlight switch. White 12
Trunk Release Orange/Blue 2 5-Wire BCM behind glove box. Gray 16
Door Lock (WO/Alarm) Pink 20 MUX BCM behind glove box. Gray 24
Door Lock (W/Alarm) Green 2 MUX BCM behind glove box. Gray 24
Mazda 3 2010-2013
12V Orange 8 (+) Ignition switch. White 8
Ignition Blue 1 (+) Ignition switch. White 8
Accessory White 6 (+) Ignition switch. White 8
Starter Lt. Green 5 (+) Ignition switch. White 8
HS CAN High White 6 Data OBDII. Black 16
HS CAN Low Red 14 Data OBDII. Black 16
RX Blue 1 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
TX Lt. B lue 2 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
Parking Light Gray 23 (-) BCM Above Driver kick panel. White 24
Trunk Release Brown 8 (-) BCM Above Driver kick panel. White 24
Door Lock (WO/Alarm) Lt. Green 14 MUX BCM Above Driver kick panel. White 24
Door Lock (W/Alarm) Green 13 MUX BCM Above Driver kick panel. White 24
Mazda 5 2011-2016
12V Blue/Black 8 (+) Ignition switch. White 8
Ignition Blue 1 (+) Ignition switch. White 8
Accessory Black/Red 6 (+) Ignition switch. White 8
Starter Blue/Red 5 (+) Ignition switch. White 8
HS CAN High Green/Yellow 6 Data OBDII. Black 16
HS CAN Low Red/Yellow 14 Data OBDII. Black 16
RX Gray 1 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
TX Blue/Orange 2 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
Parking Light Brown/Red 23 (-) BCM behind glove box. Blue 24
Trunk Release Violet/Yellow 8 (-) BCM behind glove box. White 24
Door Lock (W/Alarm) Blue 14 MUX BCM behind glove box. White 24
