Xpresskit DBALL2 User Manual

Rev.: 20170926
Platform: DBALL2
Firmware: MA2
© 2017 Directed. All rights reserved.
Page 5
Type 1 - Vehicle Wiring Reference Chart
Wire Information Connector Information
Function Wire Color Pin Polarity Location
Color Pins
Mazda 6 2009-2013
12V Red/Blue 6 (+) Ignition switch. White 6
Ignition Green/Yellow 2 (+) Ignition switch. White 6
Accessory Pink/Yellow 4 (+) Ignition switch. White 6
Starter Gray/Red 1 (+) Ignition switch. White 6
HS CAN High Gray/Red 6 Data OBDII. Black 16
HS CAN Low Blue/Red 14 Data OBDII. Black 16
RX White/Green 3 Data
Immobilizer Module around ignition switch.
(PATS connector B).
White 8
TX Gray/Orange 4 Data
Immobilizer Module around ignition switch.
(PATS connector B).
White 8
Parking Light Black/White 14 (-) Headlight switch. White 17
Trunk Release Black/Red 28 (-) BCM Above Driver kick panel. White 30
Door Lock (WO/Alarm) Black/White 4 MUX BCM Above Driver kick panel. White 16
Door Lock (W/Alarm) Black 14 MUX BCM Above Driver kick panel. White 16
Mazda CX-7 2010-2011
12V Red 6 (+) Ignition switch. White 6
Ignition Dk. Green/Yellow 2 (+) Ignition switch. White 6
Accessory Pink/Yellow 4 (+) Ignition switch. White 6
Starter Gray/Red 1 (+) Ignition switch. White 6
HS CAN High Gray/Dk. Blue 6 Data OBDII. Black 16
HS CAN Low Dk. Blue/White 14 Data OBDII. Black 16
RX White/Dk. Green 1 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
TX Gray/Orange 2 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
Parking Light Black/Dk. Blue 14 (-) Headlight switch. White 17
Trunk Release Black/Red 17 (-) BCM Above Driver kick panel. White 30
Door Lock (WO/Alarm) Green/Red 14 MUX BCM Above Driver kick panel. White 30
Door Lock (W/Alarm) Black/White 11 MUX BCM Above Driver kick panel. White 30
Mazda CX-7 2010-2012 (Smart Key)
12V Red 6 (+) Ignition switch. White 6
Ignition Dr. Green/Yellow 2 (+) Ignition switch. White 6
Accessory Pink/Yellow 4 (+) Ignition switch. White 6
Starter Gray/Red 1 (+) Ignition switch. White 6
HS CAN High Gray/Dk. Blue 6 Data OBDII. Black 16
HS CAN Low Dk. Blue/White 14 Data OBDII. Black 16
RX White/Dk. Green 1 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
TX Gray/Orange 2 Data
Immobilizer Module around ignition switch.
(PATS connector C).
White 4
Parking Light Black/Dk. Blue 14 (-) Headlight switch. White 17
Trunk Release Black/Red 17 (-) BCM Above Driver kick panel. White 30
Door Lock (WO/Alarm) Green/Red 14 MUX BCM Above Driver kick panel. White 30
Door Lock (W/Alarm) Black/White 11 MUX BCM Above Driver kick panel. White 30
