Type 2 - Vehicle Wiring Reference Chart
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins
Mazda RX-8 2004-2011
Ignition Black/Yellow or Blue/Black 2 (+) Ignition switch. White 6
Accessory Blue/Green 6 (+) Ignition switch. White 6
Starter White/Blue 1 (+) Ignition switch. White 6
HS CAN High Blue/White 6 Data OBDII. Black 16
HS CAN Low Green/Black 14 Data OBDII. Black 16
RX Yellow/Black 1 Data Immobilizer Module around ignition switch. White 4
TX Blue/Orange 2 Data Immobilizer Module around ignition switch. White 4
Parking Light Lt. Green 14 (-) Headlight switch. White 17
Door Lock (WO/Alarm) Lt. Green N/A MUX Driver door harness. N/A N/A
Door Lock (W/Alarm) Green/Red N/A MUX Driver door harness. N/A N/A
12V Green or Orange N/A (+) Drivers kick panel. N/A N/A
