Xpresskit DBALL2 User Manual

Rev.: 20170926
Platform: DBALL2
Firmware: MA2
© 2017 Directed. All rights reserved.
Page 17
Type 6 - Vehicle Wiring Reference Chart
Function Wire Color Pin Polarity Location
Color Pins
Mazda Tribute 2008-2011
12V Blue/Red 4 (+) Ignition switch. Black 7
Ignition White/Orange 1 (+) Ignition switch. Black 7
Accessory Violet/Green 6 (+) Ignition switch. Black 7
Starter Blue/White 7 (+) Ignition switch. Black 7
HS CAN High White/Blue 6 Data OBDII. Black 16
HS CAN Low White 14 Data OBDII. Black 16
MS CAN High Gray/Orange 3 Data OBDll Black 16
MS CAN Low Violet/Orange 11 Data OBDll Black 16
RX Violet/Gray 3 Data Immobilizer Module around ignition switch. Black 4
TX Yellow/Orange 4 Data Immobilizer Module around ignition switch. Black 4
Parking Light Violet/White N/A (+) Driver kick panel. N/A N/A
Door Lock Blue/Green 17 (-) Driver door harness. N/A N/A
Door unlock Yellow/Violet 4 (-) Driver door harness. N/A N/A
Rear liftgate Brown 7 (-) SJB (Smart Junction Box) right side of center console. Gray 26
Wire Information
Connector Information
