Xpresskit DBALL2 User Manual

Rev.: 20170926
Platform: DBALL2
Firmware: MA2
© 2017 Directed. All rights reserved.
Page 19
Type 7 - Vehicle Wiring Reference Chart
Function Wire Color Pin
Polarit
Location
Color Pins
Mazda Tribute 2005-2007
12V Red 4 (+) Ignition switch. Black 7
Ignition Lt. Green/Violet 1 (+)
Ignition switch. Black 7
Accessory Black/Lt. Green 6 (+) Ignition switch. Black 7
Starter Tan/Lt. Blue 7 (+) Ignition switch. Black 7
HS CAN High White 6 Data OBDII. Black 16
HS CAN Low Black 14 Data OBDII. Black 16
RX Red/Black 3 Data Immobilizer Module around ignition switch. Green 4
TX Brown/Orange 4 Data Immobilizer Module around ignition switch. Green 4
Parking Light Brown N/A (+) Driver kick panel. N/A N/A
Door Lock/Unlock Pink/White MUX N/A Driver kick panel. N/A N/A
Wire Information
Connector Information
