5 Physical Specifications
5.1 Sensor specifications
The specifications apply to Xsens DOT 2
nd
generation sensor.
Table 12: Xsens DOT sensor specifications
Physical Properties
Attachment
Application dependant, straps available by Xsens (sold
separately)
Latency
30 ms
Battery life
Up to 9 hours (continuous use)
Weight
11.2 g
Dimensions
36.3 x 30.4 x 10.8 mm (l x w x h)
Operating temperature range
0 – 50 °C
Storage temperature range
25 ±10 °C
IP Rating
IP68
Internal storage
64 MB
Recording time
Depends on output rate, 6 hours @60Hz
Synchronization accuracy
1 ppm for 30 min, <4 ppm for 1 hour
Internal sampling rate
800 Hz
Output rate
1Hz, 4Hz, 10Hz, 12Hz, 15Hz, 20Hz, 30Hz, 60Hz and 120Hz
(120Hz is only for recording)
Communication
Best performance with Bluetooth 5.0 devices
Communication platforms
• Android OS 8.0 or above
• iOS 11.0 or above
• Windows, MacOS, Raspberry Pi
Operating frequency range
2401 - 2480 MHz
Max radiated output power with
internal antenna (EIRP)
+5 dBm
Table 13: Orientation Performance
Orientation
Accuracy
Static (Inclination | Heading)
0.5° | 1.0° 1σ RMS
Dynamic (Inclination | Heading)
1.0° | 2.0° 1σ RMS
5.2 Charger specifications
The specifications apply to Xsens DOT 2
nd
generation charger.
Table 14: Charger specifications
Physical Properties
Weight
115 g (without DOTs)
Dimensions
183.6 x 53.6 x 21.1 mm (l x w x h)
USB communication hub
Yes
Operating voltage
5V
Power consumption
120 mA (460 mA with DOTs)
Operating temperature range
0-70 °C
Storage temperature range
40-100 °C
Environmental humidity range
20-80%RH NC
