ForeSite SS Hardware34
For a SOILED Sensor:
10
1:10
11
1:10
789
13
14
12
cl
1 : 10
1:10
1:10
1:10
1:10
H
2
O
H
H
2
H2O
H
2
O
H
21 345
6
H2O
H
2
O
H2O
H
2
O
15
H
2
O
1. Lay the soiled sensor on a at surface.
2. Prepare a 1:10 cleaning soluon (1 bleach : 10 water).
3. Dip a so bristle (M16) brush into cleaning soluon.
4. Scrub surface with the brush.
5. Wet a so cloth with tap water.
6. Wipe o residual cleaning soluon with the wet cloth.
7. Allow surface to dry.
8. Wet a so cloth with 1:10 cleaning soluon.
9. Wipe the sensor with a so cloth moistened with
cleaning soluon.
10. Allow sensor to dry for 3 minutes.
11. Dip a fresh, clean so cloth into 1:10 cleaning soluon.
12. Clean sensor with clean, moist cloth unl all visible
debris removed.
13. Wet a clean, so cloth with tap water.
14. Wipe residual soluon o with wet cloth.
15. Allow sensor to dry.
