ForeSite SS Soware
49
Pressure Imaging
Once a client le is opened, the Live Image tab will become acve. To view
the live pressure image, select the main Live Image tab.
To Rotate the Pressure Image
1. Select unl the pressure image rotates to the desired orientaon
To View the 3x3 Peak Pressure Index (PPI)
1. Select an area of the pressure image and hold
To Take a Pressure Image Snapshot
1. Select directly below the live pressure image (opens snapshot on the
Review tab)
2. Enter a tle for your snapshot
3. Select to capture notes for your snapshot
→ Snapshots are automacally saved to Gallery as soon as they are taken
To Take a Pressure Image Recording
1. Toggle the camera/recorder icon to the recorder icon (it will
turn blue)
2. Select to begin recording
3. Select the red stop buon when you wish to stop recording
4. Enter a tle for your recording
5. Select to capture notes for your recording
→ Recordings are automacally saved to Gallery as soon as they are taken
ToResettheSelingTime
1. Select the refresh icon next to the digital mer
To Adjust the Upper and Lower Pressure Thresholds
1. Select the upper/lower red arrows and drag them to the desired pressure
values
