ForeSite SS Soware50
To View the Pressure Image in 3D
1. Select the 3D icon
→ Re-select the icon to return to 2D
To Pin a Note or Anatomical Marker to the Pressure Image
1. Select
2. Select and hold the area on the pressure image where you would like to
place it
3. Select the desired type from the list
→ Note (Select the text area below the Note selecon to enter text)
- Coccyx
- LIT: le ischial tuberosity
- RIT: right ischial tuberosity
- RGT: right greater trochanter
- LGT: Le greater trochanter
→ Selecng both the LIT and RIT anatomical markers will invoke a line of
symmetry on the pressure image
To Delete a Note or Anatomical Marker
1. Select the previously placed note or anatomical marker
2. Select the delete icon
