Reviewing Snapshots and Recordings
Once selected, gallery items (snapshots and recordings) open on the main
Review tab. From here, users can review the pressure image more carefully,
make changes and also capture more pressure image-related data. Users
also have many of the same features available on the Live Image tab including
rotang the pressure image, viewing it in 3D, viewing the 3X3 PPI, adjusng
pressure limits, and pinning notes and anatomical markers.
Select an item from the Gallery tab to view it on the main Review tab.
To View Notes Captured on a Gallery Item
(where notes have been previously captured)
1. Select the note icon on the pressure image to expand and view the note
To Edit Snapshot/Recording Title or Notes
1. Select
2. Select item tle eld to make changes
3. Select to make changes to item notes
To Playback a Recording
1. Select the play buon below the recording
To Capture a Single Frame from a recording
1. Select the play buon below the recording
2. While the recording is playing back, select to capture a single frame
→ Single frames are reected in the Gallery with the same red ag icon that
appears on the capture icon
