ForeSite SS Soware
53
To Capture the Average Frame from a Recording
1. Toggle the single/average frame icon to the average frame
icon
2. Drag the red arrows on the recording progress bar to the desired me
frames within the recording. Time frames are indicated directly below the
recording progress bar.
3. Select to capture the average frame
→ Average frames are reected in the Gallery with the same red arrows icon
that appears on the capture icon
To View Compared Pressure Images as a Quadrant or in Columns
1. Once the Compare feature has been iniated from the Gallery (described
above), select for column view and for quadrant view
→ Column view displays the pressure image stascs below the pressure
To Save Compared Pressure Images
1. Select directly below the compared images
2. Enter a tle for your comparison
3. Select to capture notes for your comparison
→ Saved comparisons are automacally saved to Gallery
To Share/Export Compared Pressure Images
1. Select
