Page 44 DPA Series DPA80/DPA100 Operating Instructions
t
a
x
1<B>2 Output 1 Gain
Output Gain = 0.0dB
Depending on what bridged mode are active the appropriate LED will illuminate above the
power switch:
There are some changes operationally
when a pair of channels are bridged.
Channel MUTE keys will be automatically
ganged;
Meters for the bridge pair will read
identically;
and lastly
Channel EDIT keys will be automatically ganged, and the display reflects the bridged mode
by changing to show the following when a bridged pair are edited:
In this example, the bridged pair are outputs 1 & 2 and this will be displayed if EDIT is pressed
on either output channel.
Bridged status is stored in an output memory, and ignored if this memory is recalled into the
auxiliary channels.
