Page 64 DPA Series — DPA80/DPA100 Operating Instructions
t
a
x
Power Consumption and Thermal Emissions — DPA 80
Mains
(V)
Load
(R)
Current Draw
(A)
Thermal Emissions
(W)
No Sig’l Light Average Heavy No Sig’l Light Average Heavy
240 8
1.5 2.2 3.4 6.3 360 378 410 486
240 4
1.5 2.8 5.0 10.3 360 394 453 593
240 2
1.5 3.1 5.8 12.4 360 402 474 647
120 8
3.3 4.7 7.1 12.9 400 418 450 526
120 4
3.3 5.9 10.4 21.0 400 434 493 633
120 2
3.3 6.5 12.0 25.1 400 442 514 687
Power Consumption and Thermal Emissions — DPA 100
Mains
(V)
Load
(R)
Current Draw
(A)
Thermal Emissions
(W)
No Sig’l Light Average Heavy No Sig’l Light Average Heavy
240 8
2.1 3.2 5.1 9.6 504 533 582 701
240 4
2.1 4.1 7.5 15.7 504 557 647 863
240 2
2.1 4.6 8.9 19.1 504 570 682 953
120 8
4.7 6.9 10.6 19.6 560 589 638 757
120 4
4.7 8.7 15.5 31.9 560 613 703 919
120 2
4.7 9.7 18.2 38.7 560 626 738 1009
No Sig’l = Quiescent, Light = Crest Factor of 7.8(18dB),
Average = Crest Factor of 4.8(14dB), Heavy = Crest Factor of 2.8(9dB)
For details of measurement methods please refer to the Technical Support area of our website.
