ET5000 User Manual The gateway for Smart Linux TV
(G) Technical Data
ET5000 Technical Specifications
Front Panel
Buttons 5 (Standby/Up/Down/Left/Right)
Status Indicator 3 (Red/Green/Yellow)
USB 1 x USB 2.0
Smartcard reader slot 2
Rear Panel
Power Switch 1
Sat-IF input/output 1 x F-type socket
Video output(analogue) 3 x RCA (YPbPr)/1 x RCA (Composite)
Video/audio output (digital) 1 x HDMI
Audio output (analogue) 2 x RCA
Audio output (digital) Standard optical (S/PDIF)
USB 2 x USB 2.0
Ethernet 1
RS-232 1
Power
Mains voltage 950~250/50~60 V/Hz
Power consumption
(Max./typ. operation/stand-by)
30/20/1 W
RF
RF range 950~2,150 MHz
Modulation, FEC, de-multiplexer DVB-S/DVB-S2 standard
Video
Video resolution CCIR 601 (720x576 lines), 576p, 720p, 1080i, 1080p@30
Video decoding MPEG-2, MPEG-4 compatible
Input data rate 2~45 MSymb/s
S/N
> 53 dB
Decoding
Decoding AC 3, MPEG-4 (AAC-HE), MPEG-1, Layer 1, 2 and 3
Sampling rate 32/4.1/48 kHz
S/N
> 65 dB
LNB
LNB supply(horiz./vert.) 14/18 ; Max. 400mA
Control signal 22kHz ; ToneBurst ; DiSEqCTM1.0/1.1/1.2
General
Dimensions (W x H x D) 260 x 45 x 220 mm
Weight (without HDD) App. 2kg
