en - Original instructions
e-SV series - Installation, Operation and Maintenance Manual 17
4 Installation
4.1 Precautions
Make sure you have read and understood the safety instructions in the Introduction and Safety
chapter before starting work.
DANGER: Potentially explosive atmosphere hazard
It is prohibited to start the unit in environments with potentially explosive atmospheres or with
combustible dusts
WARNING:
Always wear personal protective equipment.
WARNING:
Always use suitable working tools.
WARNING:
When selecting the place of installation and connecting the unit to the hydraulic and electric
power supplies, strictly comply with current regulations.
When connecting the unit to a public or private aqueduct, or to a well for the supply of water
for human and/or animal consumption:
WARNING:
It is prohibited to pump drinking water after use with other fluids.
WARNING:
Remove the unit from its packaging just before installation to prevent contamination from
external substances.
WARNING:
Observe all the provisions of the authorities and companies concerned.
4.2 Mechanical installation
Install the unit on a concrete or metal foundation base sufficiently strong to ensure permanent
and rigid support.
4.2.1 Installation area
1. Place the unit in a raised position in relation to the floor.
2. Make sure that any leaks will not cause flooding to the installation area or submerge the
unit.
3. Comply with the provisions of the Operating environment section.
Air clearance between a wall and the motor fan grille
To ensure suitable ventilation: ≥ 100 mm
To permit inspection and removal of the motor: ≥ 300 mm.
