Yale Assure Lock 2 User Manual

21
P/N YRD604-KD-BLE-0047 Rev A
1. Remove one side of the backing from the adhesive.
2. Attach tape to the back of the DoorSense, ensuring it is aligned with
the edges of the device and the screw holes.
3. Remove the remaining backing from the adhesive.
4. Determine mounting location. For optimal performance, DoorSense
should be mounted within 11/2” from the edge of your door frame.
5. Ensure DoorSense is in proper position by center aligning it with the
Yale logo on the battery cover, and adhere it to the door frame.
6. Tighten pre-installed screws and attach cover.
It is recommended to complete the last step after your lock
is calibrated with the app to ensure you are able to retrieve
accurate door state readings before modifying your frame.
1 4
5
2
3
6
11/2”
9b
DoorSense Surface Mount

Yale Assure Lock 2 Specifications

General

Lock Type	Deadbolt
Connectivity	Bluetooth, Wi-Fi (with module)
Power Source	4 AA Batteries
Battery Life	Up to 1 year
Auto-Lock	Yes
Weight	Varies by model
Keypad Type	Touchscreen
Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Installation	DIY, fits standard doors
Door Thickness Compatibility	1-3/8" to 2-1/4"
User Codes	Up to 25
Weather Resistance	Weather resistant
Backset	Adjustable 2 3/8" or 2 3/4"
Warranty	1-year on electronic parts
Finish	Satin Nickel, Oil Rubbed Bronze, Black Suede
Backup Power	9V battery terminal
