62 MIXING Display Functions
02R User’s Guide
38 Piano High
PEAKING PEAKING PEAKING PEAKING Use for the high range of
the piano sound when it is
recorded in stereo. Use
with program 37.
Q 10 6.3 2.2 0.1
F 187Hz 397Hz 6.72kHz 5.65kHz
G –5.5dB +1.5dB +5.0dB +3.0dB
39 Fine-EQ(Cass)
L.SHELF PEAKING PEAKING H.SHELF Use for recording to or
from cassette tape to
make the sound clearer.
Q 4.5 1.8
F 74Hz 1.00kHz 4.00kHz 12.6kHz
G –1.5dB 0.0dB +1.0dB +3.0dB
40 Narrator
PEAKING PEAKING PEAKING H.SHELF Use for recording a voice
reading a text.
Q 4 7 0.63
F 105Hz 707Hz 2.52kHz 10.0kHz
G –4.0dB –1.0dB +2.0dB 0.0dB
Note: The EQ programs were programmed for recording acoustic musical instruments. If you are using them for a
sampler, synthesizer, or rhythm machine, adjust the parameters accordingly.
Note: Programs 33 to 40 contain preset programs and are listed in the table above. However, you can store your own
settings to these programs.
No Name
Parameter
Description
LOW L-MID H-MID HIGH
