MIXING Display Functions 61
02R User’s Guide
30 Total EQ 1
PEAKING PEAKING PEAKING H.SHELF Use on the STEREO bus
during mixdown. For more
effect, try it with a
compressor.
Q 7 2.2 5.6
F 94Hz 944Hz 2.11kHz 16.0kHz
G –0.5dB 0.0dB +3.0dB +6.5dB
31 Total EQ 2
PEAKING PEAKING PEAKING H.SHELF This is a variation on
program 30.
Q 7 2.8 5.6
F 94Hz 749Hz 1.78kHz 17.9kHz
G +4.0dB +1.5dB +2.0dB +6.0dB
32 Total EQ 3
L.SHELF PEAKING PEAKING H.SHELF This is a variation on
program 30. Also use
these programs for stereo
inputs or external effect
returns.
Q 0.28 0.7
F 66Hz 841Hz 1.88kHz 15.1kHz
G +1.5dB +0.5dB +2.0dB +4.0dB
33 Bass Drum 3
PEAKING PEAKING PEAKING PEAKING This is a variation on
program 1. The low and
mid range is removed.
Q 2 10 0.4 0.4
F 118Hz 315Hz 4.23kHz 20.1kHz
G +3.5dB –10.0dB +3.5dB 0.0dB
34 Snare Drum 3
L.SHELF PEAKING PEAKING PEAKING This is a variation on
program 3. It creates
rather thick sound.
Q 4.5 2.8 0.1
F 223Hz 561Hz 4.23kHz 4.00kHz
G 0.0dB +2.0dB +3.5dB 0.0dB
35 Tom-tom 2
L.SHELF PEAKING PEAKING H.SHELF This is a variation on
program 5. Emphasizes
the mid and high range.
Q 4.5 1.2
F 88Hz 210Hz 5.33kHz 16.9kHz
G –9.0dB +1.5dB +2.0dB 0.0dB
36 Piano 3
PEAKING PEAKING PEAKING H.SHELF This is a variation on
program 13.
Q 8109
F 99Hz 472Hz 2.37kHz 10.0kHz
G +4.5dB –13.0dB +4.5dB +2.5dB
37 Piano Low
PEAKING PEAKING PEAKING H.SHELF Use for the low range of
the piano sound when it is
recorded in stereo. Use
with program 38.
Q 10 6.3 2.2
F 187Hz 397Hz 6.72kHz 12.6kHz
G –5.5dB +1.5dB +6.0dB 0.0dB
No Name
Parameter
Description
LOW L-MID H-MID HIGH
