Yamaha 02R Version 2 - Page 162

60 MIXING Display Functions
02R User’s Guide
20 A.G.Stroke 1
PEAKING PEAKING PEAKING H.SHELF Emphasizes the bright
tones of an acoustic
guitar.
Q 0.9 4.5 3.5
F 105Hz 1.00kHz 1.88kHz 5.33kHz
G –2.0dB 0.0dB +1.0dB +4.0dB
21 A.G.Stroke 2
L.SHELF PEAKING PEAKING H.SHELF This is a variation on
program 20. You can also
use it for the electric gut
guitar.
Q 9 4.5
F 297Hz 749Hz 2.00kHz 3.56kHz
G –3.5dB –2.0dB 0.0dB +2.0dB
22 A.G.Arpeggio 1
L.SHELF PEAKING PEAKING PEAKING Corrects arpeggio
technique of an acoustic
guitar.
Q 4.5 4.5 0.12
F 223Hz 1.00kHz 4.00kHz 6.72kHz
G –0.5dB 0.0dB 0.0dB +2.0dB
23 A.G.Arpeggio 2
L.SHELF PEAKING PEAKING H.SHELF This is a variation on
program 22.
Q 7 4.5
F 177Hz 354Hz 4.00kHz 4.23kHz
G 0.0dB –5.5dB 0.0dB +4.0dB
24 Brass Section
PEAKING PEAKING PEAKING PEAKING Use with trumpets,
trombones, or sax. With
one instrument, adjust the
HIGH or H-MID frequency.
Q 2.8 2 0.7 7
F 88Hz 841Hz 2.11kHz 4.49kHz
G –2.0dB +1.0dB +1.5dB +3.0dB
25 Male Vocal 1
PEAKING PEAKING PEAKING PEAKING Use as a template for male
vocal. Adjust the HIGH or
H-MID setting according
to the voice quality.
Q 0.11 4.5 0.56 0.11
F 187Hz 1.00kHz 2.00kHz 6.72kHz
G –0.5dB 0.0dB +2.0dB +3.5dB
26 Male Vocal 2
PEAKING PEAKING PEAKING H.SHELF This is a variation on
program 25.
Q 0.11 10 5.6
F 167Hz 236Hz 2.67kHz 6.72kHz
G +2.0dB –5.0dB +2.5dB +4.0dB
27 Female Vocal 1
PEAKING PEAKING PEAKING PEAKING Use as a template for
female vocal. Adjust the
HIGH or H-MID setting
according to the voice
quality.
Q 0.18 0.45 0.56 0.14
F 118Hz 397Hz 2.67kHz 5.99kHz
G –1.0dB +1.0dB +1.5dB +2.0dB
28 Female Vocal 2
L.SHELF PEAKING PEAKING H.SHELF This is a variation on
program 27
Q 0.16 0.2
F 111Hz 334Hz 2.00kHz 6.72kHz
G –7.0dB +1.5dB +1.5dB +2.5dB
29 Chorus & Harmony
PEAKING PEAKING PEAKING PEAKING Use as a template for a
chorus. It makes the entire
chorus much brighter.
Q 2.8 2 0.7 7
F 88Hz 841Hz 2.11kHz 4.49kHz
G –2.0dB +1.0dB +1.5dB +3.0dB
No Name
Parameter
Description
LOW L-MID H-MID HIGH
