Internal Effects 123
02R User’s Guide
Program 34 — FLANGE
Stereo flanger. Creates a rich, swirling effect, full of harmonics.
Parameter Setting Range Description
Freq. 1.2Hz 0.1–40.0Hz Modulation frequency.
Depth 25% 0–100% Modulation depth.
FB.Gain +45% –99 to +99% Feedback gain. The amount of signal returned to the effect.
LSF F 63Hz 32Hz–1.0kHz Low shelving filter frequency.
LSF G 0dB –12 to +12dB Low shelving filter gain.
Mod.Dly 14.6ms 0.0–255.0ms Flange delay. The delay time before modulation starts.
EQ F 630Hz 160Hz–8.0kHz Equalizer frequency.
EQ G +2dB –12 to +12dB Equalizer signal gain.
HSF F 3.2kHz 1.0–10.0kHz High shelving filter frequency.
HSF G 0dB –12 to +12dB High shelving filter gain.
Program 35 — SYMPHONIC
This program creates a rich and grand chorus effect, bigger than chorus alone.
Parameter Setting Range Description
Freq. 0.6Hz 0.1–40.0Hz Modulation frequency.
Depth 8% 0–100% Modulation depth.
Mod.Dly 2.4ms 0.0–255.0ms Modulation delay. The delay time before modulation starts.
LSF F 63Hz 32Hz–1.0kHz Low shelving filter frequency.
LSF G 0dB –12 to +12dB Low shelving filter gain.
EQ F 500Hz 160Hz–8.0kHz Equalizer frequency.
EQ G 0dB –12 to +12dB Equalizer signal gain.
HSF F 6.3kHz 1.0–10.0kHz High shelving filter frequency.
HSF G –2dB –12 to +12dB High shelving filter gain.
Program 36 — TREMOLO
A stereo tremolo, just like on a classic guitar amplifier. It creates a fat sound that is great with guitars.
Parameter Setting Range Description
Freq. 3.1Hz 0.1–40.0Hz Modulation frequency.
AM Depth 84% 0–100% Amplitude modulation depth.
PM Depth 6% 0–100% Pitch modulation depth.
LSF F 250Hz 32Hz–1.0kHz Low shelving filter frequency.
LSF G +2dB –12 to +12dB Low shelving filter gain.
EQ F 630Hz 160Hz–8.0kHz Equalizer frequency.
EQ G +1dB –12 to +12dB Equalizer signal gain.
HSF F 2.8KHz 1.0–10.0kHz High shelving filter frequency.
HSF G +1dB –12 to +12dB High shelving filter gain.
